Key Features
High reliability and outstanding performance.
A wide range of speed from 50 to 2200rpm.
Brushless DC motor for long life, maintenance free and explosion proof.
LED screen for monitoring actual speed.
Safety circuits allow for safe stop function in anti-stall or overload conditions.
| Specifications | OS40-S |
| Max. stirring quantity(H2O) | 40L |
| Motor type | brushless DC motor |
| Motor input power | 120W |
| Motor output power | 100W |
| Voltage | 100-240V, 50/60 Hz |
| Power | 130W |
| Speed range | 50-2200rpm |
| Speed display accuracy | ±3rpm |
| Speed display | LED |
| Overload protection display | LED lights |
| Max. torque | 60Ncm |
| Viscosity max. | 50000mPas |
| Chuck range diameter | 0.5-10mm |
| Dimension[WxHxD] | 83x.220x186mm |
| Weight | 2.8kg |
| Protection class | IP42 |
| Permissible ambient temperature and humidity | 5-40°C 80%RH |
