| Specifications | |
| Nominal current range | 200 A |
| Continuous current range | 0.5 A - 200 A |
| Maximum Non-Destructive Current | 240 A |
| Lowest measurable current | 0.5 A |
| Basic Accuracy | 1% + 0.5 A (48-65 Hz) (% reading + floorspec) |
| Useable frequency | 40 Hz - 10 kHz |
| Output level(s) | 1 mA/A |
| Safety Specifications | |
| Safety | CAT III, 600 V |
| Maximum voltage | 600 V AC |
| Mechanical & General Specifications | |
| Warranty | 1 year |
| Maximum conductor diameter | 20 mm |
| Maximum conductor size (busbar) | 20 x 5 mm |
| Output cable length | 1.5 m |
| Shrouded banana plugs | Yes |
